AIRCRAFT DIMENSIONS & WEIGHT

Length	5.65 m
Wing span	9.80 m
Max height	2.55 m
Wheel track	1.60 m
Wheel base	1.45 m
Empty weight (50 HP, no options)	230 Kg
Empty weight (65 HP, full options)	240 Kg

GENERAL CONFIGURATION:

• 2-SEATER, SIDE - BY - SIDE.
• CONVENTIONAL 3 AXIS CONTROLS.
• AILERONS, ELEVATOR & RUDDER.
• FULL DUAL CONTROLS.
• FRONT MOUNTED PULLER ENGINE. HIGH WING.
• TRICYCLE LANDING GEAR, WITH SUSPENSION.
• STEERABLE NOSE WHEEL, LINKED TO RUDDER PEDALS.
• TOE OPERATED DIFFERENTIAL BRAKES.
• ENCLOSED COCKPIT, LEXAN WINDSCREEN, ENCLOSED FUSELAGE. ELEVATOR TRIM.
• "DUC" CARBON PROPELLER. ELECTRIC SELF STARTER.
• ELECTRIC BACK-UP FUEL PUMP.

STANDARD INSTRUMENTATION:

• TACHOMETER.
• WATER TEMPERATURE.
• AIR SPEED INDICATOR.
• TURN & SLIP INDICATOR ( BALL ).
• ALTIMETER.
• BATTERY CHARGE INDICATOR.


STANDARD ENGINE SPECS:

• 65 BHP ROTAX - TYPE 582 - 2V, MADE IN AUSTRIA.
• DOUBLE ELECTRONIC IGNITION, WITH 2 PLUGS PER CYLINDER.
• DOUBLE CARBURETORS - BING MAKE. LIQUID COOLED.
• ROTARY INTAKE VALVE. GEAR BOX - TYPE "C" 3 RATIO.
